基本信息 | |
---|---|
商品编号 | 2BA 013 236-141 |
GTIN/EAN 编号 | 04082300407211 |
包装单位 | 1 |
每个包装单位的数量 | |
状态 | 正常的 |
使用代码 |
信息 |
---|
技术信息 |
Regarding flasher lights with LEDs with active electronics In connection with these low powers, which are very differen t from bulb versions, there can be problems with the bulb fa ilure check during operation on various traction vehicles. Since indicator failure checks are required by legislation, we recommend only operating the light in combination with an indicator control unit part no. "5DS 009 602-¿, 5DS 009 552-¿ or LED flasher unit 4.. 009 492". Operation of the light with alternating current or pulsed di rect current is not permitted! The individual light functions may only be operated with a v ehicle fuse of max. 3A. |
生产商地址 | |
---|---|
姓名 | HELLA |
名称补充 | HELLA GmbH & Co. KGaA |
街道 | Rixbecker Str. 75 |
国家 | DE |
城市 | Lippstadt |
邮政编码 | 59552 |
电话 | 01 80-6-25 00 01 |
传真 | 01 80-2-25 00 01 |
电子邮件 | technischer.kundendienst@hella.de |
网址 | http://www.hella.de |
标准 | |
---|---|
装配方式 | 安装, 加工螺纹的 |
照明-结构形式 | LED |
灯泡种类 | LED |
电压 | 12 伏特 |
安装位置 | 后 |
长度 | 138 毫米 |
宽度 | 116 毫米 |
高度 | 66 毫米 |
照明功能 | 带方向灯(LED) |
光源有几种功能 | 1 |
插入件 | 扁平插头 |
防护类型 | IPX9K, IP5KX |
检查记号 | ECE-R6, ADR/GGVS |
发光二极管的数量 | 6 |
灯罩的颜色 | 透明玻璃 |
电缆长度 | 100 毫米 |
填充件/补充信息2 | 带转向灯失效控制 |
量 | 1 |
需要由专业人员安装/拆卸! |
